Product Description:
This LCD Display Module is designed with a TFT Lcd Panel Interface
of HDMI, a Touch Panel Interface of USB, a Display Backlight of
White LED, and a Operating Temperature of -30℃ ~ +80℃. With a color
of 16.7M, it stands out as an excellent color display screen, color
tft screen, TFT module, and LCD display module.
This LCD Display Module has a high definition resolution that
offers a wide range of color depth and contrast. It is designed
with an optimized angle of view, providing you with a great visual
experience. It also has a wide operating temperature range, making
it suitable for any environment.
Features:
- Product Name: LCD Display Module
- Module: CH103WS03A-T
- LCM Outline: 235*143*6.29 Mm
- Display Viewing Angle: 80/80/80/
- Module Type: 10.1”TFT + RTP + HDMI Board
- Display Contrast Ratio: 800:1
- Display Resolution: 1024*600 Dots
- 10.1 inch display
- Color LCD Screen
- LCD Module
- TFT LCD
- 800:1 contrast ratio
Technical Parameters:
| Parameter | Specification |
|---|
| Touch Panel Type | Resistive |
| Display Life Span | 50000H |
| Color | 16.7M |
| LCM Outline | 235*143*6.29 Mm |
| FPC Pin Number | 50 Pins |
| Display Backlight | White LED |
| Touch Panel Interface | USB |
| Display Operating Temp | -20 ~ +70℃ |
| Display Response Time | 16 Ms |
| Working Power Supply | DC12V/2A |
Applications:
The CH101WS03A-T LCD display module of Chenghao Optoelectronics is
a high-quality product certified by CE, RoHS, and FCC. It does not
have a minimum order quantity for customers. For products of
smaller size, pallets and cartons can be used for packaging. For
products of larger size, foam tanks and cartons can be used for
packaging. It can also be customized according to customer
requirements. The delivery time is usually 3-7 days, and the
payment terms can be TT or other methods. The supply capacity is
50000000 pieces per month.
The display size of the CH101WS03A-T LCD display module is 10.1
inches, with a response time of 16 milliseconds and a contrast
ratio of 800:1. It also has an FPC with 50 pins and a display
storage temperature of -30~+850 ℃. This product is widely used in
color displays, automotive LCD displays, and industrial LCD
displays.
Support and Services:
We provide technical support and service for LCD Display Module,
including:
- 24/7 customer service and technical assistance
- Free installation and setup assistance
- Troubleshooting and repair services
- Replacement of defective parts
- Warranty coverage
Packing and Shipping:
Packaging and Shipping for LCD Display Module
For the safe delivery of LCD Display Module, the following
packaging and shipping techniques are applied:
- The LCD Display Module is packed in a bubble wrap bag to ensure
that it is not damaged in transit.
- The LCD Display Module is then placed in a sturdy cardboard box.
- The package is then sealed with a protective tape.
- The package is shipped to the customer via a reliable shipping
carrier.
FAQ:
Q: What is the Brand Name of this LCD Display Module?
A: The Brand Name of this LCD Display Module is Chenghao
Optoelectronic.
Q: What is the Model Number of this LCD Display Module?
A: The Model Number of this LCD Display Module is CH101WS03A-T.
Q: Where is this LCD Display Module made?
A: This LCD Display Module is made in Shenzhen, China.
Q: What Certifications does this LCD Display Module have?
A: This LCD Display Module has CE, RoHS, and FCC Certifications.
Q: What is the Minimum Order Quantity for this LCD Display Module?
A: There is no Minimum Order Quantity for this LCD Display Module.
