Free Viewing Angle LCD Touch Screen Monitor 4.3 Inch FPC 40 Pin
800*480
Free Viewing Angle LCD Touch Screen Monitor 4.3 Inch 40pin RGB
800*480 TFT Display
Description of Industrial TFT Display
Chenghao Optoelectronic CH430WV11A-CTB is a Full Color Lcd Touch
Screen Module. The touch screen module has an active display area
with a diagonal length of 4.3 inches, a resolution of 800*480
pixels, and can display color images with a contrast ratio of 800
and 16M colors. Thanks to the installed Capacitive touch panel,
this touch screen monitor supports multi-touch for human-computer
interaction. In order to make it easier for users to read the
screen flexibly, CH430WV11A-CTB adopts IPS/Transmissive/Normally
Black display mode, and its best viewing angle is extended to
80/80/80/80 (free viewing angle), which greatly improves the user's
viewing angle. Product experience. By the way, this touch screen
display module is also a wide temperature display, which can be
stored in an environment of -30~+80 degrees Celsius, and can
operate normally for more than 30000H in an environment of -20~+70
degrees Celsius.
In addition, Chenghao Optoelectronic, as a comprehensive enterprise
focusing on LCD R&D, production and sales, can provide
customers with one-stop customized services for LCD displays. For
CH430WV11A-CTB, we can modify FPC, TFT interface, Backlight
Luminance, etc. according to customer requirements.
Specification of Custom Capacitive Touch Panel
| Product Name | LCD Display Module |
| Module No | CH430WV11A-CTB |
| Display Mode | Normally Black/IPS/Transmissive |
| Viewing Angle | All Vierwing Angle |
| Resolution | 800*3(RGB)*480 dots |
| Module Size | 105.5*67.2*4.95 mm |
| Active Area | 95.04*53.86 mm |
| TFT Interface | RGB |
OPERATING TEMP | -20°C~+70°C |
STORAGE TEMP | -30°C~+80°C |
Quick Detail of 4.3 Inch LCD Display
Keyword LCD Touch Display
LCM Type 4.3 inch TFT+CTB
Display Mode IPS/Transmissive/Normally Black
Viewing Direction 80/80/80/80
Number of dots 800*3(RGB)*480
Contrast 800:1
Color 16.7 m
TFT Interface RGB
Touch Panel Type Capacitive Touch Panel
Touch Panel Interface I2C
Module Size 105.5*67.2*4.95 mm
Active Area 95.04*53.86 mm
FPC Pin Number 40pin
Backlight Luminance 300cd/m2
Operation Temp.:-20℃~+70℃,≤90%RH
Storage Temp.:-30℃~+80℃,≤90%RH
CTP NOTE:
Glass Lens+ITO Glass+FPC+adhesive
Glass Lens:1.1mm
Glass sensor:0.55mm
IC:GT911
Operation Voltage:2.8V-3.3 V
Transmittance:≥87％
The cover hardness:6H
Advantages of Small LCD Display Screens
* Support full viewing angle
CH430WV11A-CTB is a full viewing angle Mini TFT Display with
viewing angles of 80/80/80/80, allowing users to view the display
screen flexibly with a wide viewing angle.
* Support use in wide temperature environment
As a wide-temperature display, the CH430WV11A-CTB can operate
normally in an environment of -20~+70 degrees Celsius, and can be
stored in an environment of -30~+80 degrees Celsius.
* Support human-computer interaction
This touch screen display module has a capacitive touch panel
mounted on the surface and supports multi-touch.
