MCU 250cd/m2 LCD Touch Screen Module 8 9 16 18 Bit 32 Pin

Ask Lasest Price
Brand Name :	OEM
Model Number :	430WQ08B
Certification :	ROHS 、ISO9001 、CE
Price :	/
Payment Terms :	T/T
Supply Ability :	200K PCS / Month
Delivery Time :	7 - 15 working days

Add to Cart

Product Details
Company Profile

MCU 250cd/m2 LCD Touch Screen Module 8 9 16 18 Bit 32 Pin

4.3Inch LCD Display Module 8bit 9bit 16bit 18bit MCU interface All

Viewing 32 Pin

MCU 250cd/m2 LCD Touch Screen Module 8 9 16 18 Bit 32 Pin

MODEL NO.	430WQ08B
Module type	4.3Inc
Display Mode	TN/Normally white
Number of Dots	4803272
Viewing Direction	12O'clock
Gray Scale Inversion Direction	6O'clock
Module size	10567.23 mm
TFT Active area	95.04*53.856 mm
Interface	RGB/Oem
Luminace	250cd/㎡

MCU 250cd/m2 LCD Touch Screen Module 8 9 16 18 Bit 32 Pin

ChengHao Display model 430WQ08B is a color active matrix thin film transistor (TFT) liquid

crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model is

composed of a TFT LCD panel, a driving IC, a high brightness back-light and FPC.

This TFT LCD has a 4.3 (16:9) inch diagonally measured active display area with WQVGA

(480 horizontal by 272 vertical pixel) resolution.

The driver used for this project is the ST7282 or compatible and can display 16M colors by

24 bit R.G.B. signal input. The driver is mounted on the glass and the interconnection via FPC

including components to drive the display module. Support RGB interface.

In addition, FPC can also be customized according to customer requirements, such as modifying

back-light and FPC structure, interface definition, etc.

RoHS Compliance & Halogen Free.

MCU 250cd/m2 LCD Touch Screen Module 8 9 16 18 Bit 32 Pin

Module Type	Display Area	Display Mode
1.44 inch	25.50 * 26.50 mm	Normally White IPS, Transmissive
1.44 inch	25.50 * 26.50 mm	Normally White TN, Transmissive
1.50 inch	29.76 * 22.32 mm	Normally Black IPS, Transmissive
1.54 inch	27.72 * 27.72 mm	Normally Black IPS, Transmissive
1.54 inch	27.74 * 27.74 mm	Normally Black IPS, Transmissive
1.77 inch	28.03 * 35.04 mm	Normally White TN, Transmissive
1.80 inch	28.03 * 35.04 mm	Normally White TN, Transmissive
2.00 inch	30.60 * 40.80 mm	Normally White TN, Transmissive
2.10 inch	Circular display area	Normally White IPS, Transmissive
2.31 inch	46.75 * 35.06 mm	Normally White TN, Transmissive
2.40 inch	36.72 * 48.96 mm	Normally White TN, Transmissive
2.40 inch	36.72 * 48.96 mm	Normally White IPS, Transmissive
2.80 inch	43.20 * 57.60 mm	Normally White TN, Transmissive
2.80 inch	43.20 * 57.60 mm	Normally White IPS, Transmissive
3.00 inch	36.72 * 65.28 mm	Normally Black IPS, Transmissive
3.20 inch	48.60 * 64.80 mm	Normally White TN, Transmissive
3.50 inch	70.08 * 52.56 mm	Normally White TN, Transmissive
3.50 inch	70.08 * 52.56 mm	Normally Black IPS, Transmissive
4.00 inch	51.84 * 86.4 mm	Normally Black IPS, Transmissive
4.00 inch	71.86 * 70.18 mm	Normally Black IPS, Transmissive
4.30 inch	95.04 * 53.86 mm	Normally White TN, Transmissive
4.30 inch	95.04 * 53.86 mm	Normally Black IPS, Transmissive
5.00 inch	110.88 * 62.83 mm	Normally White TN, Transmissive
5.00 inch	108.00 * 64.8 0mm	Normally Black IPS, Transmissive
5.50 inch	68.04 * 120.96 mm	Normally Black IPS, Transmissive
6.00 inch	74.52 * 132.48 mm	Normally Black IPS, Transmissive
7.00 inch	154.08 * 85.92 mm	Normally White TN, Transmissive
7.00 inch	153.6 * 90 mm	Normally White TN, Transmissive
7.00 inch	154.21 mm * 85.92 mm	Normally Black IPS, Transmissive
8.00 inch	107.64 * 172.22 mm	Normally Black IPS, Transmissive
9.00 inch	196.61 * 114.15 mm	Normally White TN, Transmissive
10.1 inch	135.36 * 216.58 mm	Normally Black IPS, Transmissive
