ISO9001 800x480 Lcd Touch Display Module RGB 40 Pin FPC Connector

Ask Lasest Price
Brand Name :	OEM
Model Number :	CH500WV06A-CTB
Certification :	ROHS 、ISO9001 、CE
Price :	/
Payment Terms :	T/T
Supply Ability :	200K PCS / Month
Delivery Time :	7 - 15 working days

Add to Cart

Product Details
Company Profile

ISO9001 800x480 Lcd Touch Display Module RGB 40 Pin FPC Connector

5inch Tn Lcd Touch Display Module RGB Landscape Screen With 40

Pin FPC And Connector Connection

ISO9001 800x480 Lcd Touch Display Module RGB 40 Pin FPC Connector

`MODEL NO.`	`CH500WV06A-CTA`
`Module type`	`5.0"TFT + CTP`
`Display Mode`	`TN/Transmissive/Normally White`
`Operation Voltage`	`2.8V-3.3 V`
`Transmittance`	`≥87％`
`STORAGE TEMP`	`-30°C~+80°C`
`Module size`	`120.7(W)75.8(H)4.65(T)mm`
`TFT Active area`	`108(W)*64.8(H)mm`
`OPERATING TEMP`	`-20°C~+70°C`
`The cover hardness`	`6H`
`ALL BENDING RADIU`	`> 2mm`
`Drive Ic`	GT911

ISO9001 800x480 Lcd Touch Display Module RGB 40 Pin FPC Connector

ChengHao Display model CH500WV03A-CTB is a color active matrix thin film transistor (TFT)

liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This model

is composed of a TFT LCD panel, a driving IC, a high brightness back-light, a capacitive touch

panel and FPC.

This TFT LCD has a 5.0 (Landscape screen) inch diagonally measured active display area with

WVGA (800 horizontal by 480 vertical pixel) resolution.

The driver used for this project is the GT911 and can display 16M colors by 24 bit R.G.B. signal

input. The driver is mounted on the glass and the interconnection via FPC including components

to drive the display module. Support RGB interface.

In addition, FPC can also be customized according to customer requirements, such as modifying

back-light and CTP structure, interface definition, etc.

RoHS Compliance & Halogen Free.

ISO9001 800x480 Lcd Touch Display Module RGB 40 Pin FPC Connector

Module Type	Display Area	Display Mode
1.44 inch	25.50 * 26.50 mm	Normally White IPS, Transmissive
1.44 inch	25.50 * 26.50 mm	Normally White TN, Transmissive
1.50 inch	29.76 * 22.32 mm	Normally Black IPS, Transmissive
1.54 inch	27.72 * 27.72 mm	Normally Black IPS, Transmissive
1.54 inch	27.74 * 27.74 mm	Normally Black IPS, Transmissive
1.77 inch	28.03 * 35.04 mm	Normally White TN, Transmissive
1.80 inch	28.03 * 35.04 mm	Normally White TN, Transmissive
2.00 inch	30.60 * 40.80 mm	Normally White TN, Transmissive
2.10 inch	Circular display area	Normally White IPS, Transmissive
2.31 inch	46.75 * 35.06 mm	Normally White TN, Transmissive
2.40 inch	36.72 * 48.96 mm	Normally White TN, Transmissive
2.40 inch	36.72 * 48.96 mm	Normally White IPS, Transmissive
2.80 inch	43.20 * 57.60 mm	Normally White TN, Transmissive
2.80 inch	43.20 * 57.60 mm	Normally White IPS, Transmissive
3.00 inch	36.72 * 65.28 mm	Normally Black IPS, Transmissive
3.20 inch	48.60 * 64.80 mm	Normally White TN, Transmissive
3.50 inch	70.08 * 52.56 mm	Normally White TN, Transmissive
3.50 inch	70.08 * 52.56 mm	Normally Black IPS, Transmissive
4.00 inch	51.84 * 86.4 mm	Normally Black IPS, Transmissive
4.00 inch	71.86 * 70.18 mm	Normally Black IPS, Transmissive
4.30 inch	95.04 * 53.86 mm	Normally White TN, Transmissive
4.30 inch	95.04 * 53.86 mm	Normally Black IPS, Transmissive
5.00 inch	110.88 * 62.83 mm	Normally White TN, Transmissive
5.00 inch	108.00 * 64.8 0mm	Normally Black IPS, Transmissive
5.50 inch	68.04 * 120.96 mm	Normally Black IPS, Transmissive
6.00 inch	74.52 * 132.48 mm	Normally Black IPS, Transmissive
7.00 inch	154.08 * 85.92 mm	Normally White TN, Transmissive
7.00 inch	153.6 * 90 mm	Normally White TN, Transmissive
7.00 inch	154.21 mm * 85.92 mm	Normally Black IPS, Transmissive
8.00 inch	107.64 * 172.22 mm	Normally Black IPS, Transmissive
9.00 inch	196.61 * 114.15 mm	Normally White TN, Transmissive
10.1 inch	135.36 * 216.58 mm	Normally Black IPS, Transmissive
