1.5”480x240 Tft Lcd Color Monitor OTA5182A-C2 Rohs Compliant

Ask Lasest Price
Brand Name :	OEM
Model Number :	CH015B4001A
Certification :	ROHS 、ISO9001 、CE
Price :	/
Payment Terms :	T/T
Supply Ability :	200K PCS / Month
Delivery Time :	7 - 15 working days

Add to Cart

Product Details
Company Profile

1.5”480x240 Tft Lcd Color Monitor OTA5182A-C2 Rohs Compliant

Wholesale 5'' 480x240 Pixel Tft Lcd Color Monitor Rohs Compliant And

Wide Temp

1.5”480x240 Tft Lcd Color Monitor OTA5182A-C2 Rohs Compliant

MODEL NO.	CH015B4001A
LCD Type	TFT TRANSMISSIVE
Backlight	LED
Supply voltage for logic	-0.3~4.6 V
Viewing direction	6 o'clock
storage temp	-20~70℃
connector	FPC
Humidity	90%(Max60C)
Driver IC	OTA5182A-C2
Drive IC	OTA5182A-C2
operative voltage	2.8 V

1.5”480x240 Tft Lcd Color Monitor OTA5182A-C2 Rohs Compliant

ChengHao Display model CH015B4001A is a color active matrix thin film transistor (TFT)

liquid crystal display (LCD) that uses amorphous silicon TFT as a switching device. This

model is composed of a TFT LCD panel, a driving IC, a back-light and FPC.

This TFT LCD has a 1.5 (Horizontal screen) inch diagonally measured active display area

with 480*240*3-RGB resolution.

The driver used for this project is the OTA5182A-C2 or compatible and can display 16M

colors by R.G.B. signal input. The driver is mounted on the glass and the interconnection

via FPC including components to drive the display module.

In addition, FPC can also be customized according to customer requirements, such as modi

-fying back-light and FPC structure, interface definition, etc.

RoHS Compliance & Halogen Free.

1.5”480x240 Tft Lcd Color Monitor OTA5182A-C2 Rohs Compliant

Module Type	Display Area	Display Mode
1.44 inch	25.50 * 26.50 mm	Normally White IPS, Transmissive
1.44 inch	25.50 * 26.50 mm	Normally White TN, Transmissive
1.50 inch	29.76 * 22.32 mm	Normally Black IPS, Transmissive
1.54 inch	27.72 * 27.72 mm	Normally Black IPS, Transmissive
1.54 inch	27.74 * 27.74 mm	Normally Black IPS, Transmissive
1.77 inch	28.03 * 35.04 mm	Normally White TN, Transmissive
1.80 inch	28.03 * 35.04 mm	Normally White TN, Transmissive
2.00 inch	30.60 * 40.80 mm	Normally White TN, Transmissive
2.10 inch	Circular display area	Normally White IPS, Transmissive
2.31 inch	46.75 * 35.06 mm	Normally White TN, Transmissive
2.40 inch	36.72 * 48.96 mm	Normally White TN, Transmissive
2.40 inch	36.72 * 48.96 mm	Normally White IPS, Transmissive
2.80 inch	43.20 * 57.60 mm	Normally White TN, Transmissive
2.80 inch	43.20 * 57.60 mm	Normally White IPS, Transmissive
3.00 inch	36.72 * 65.28 mm	Normally Black IPS, Transmissive
3.20 inch	48.60 * 64.80 mm	Normally White TN, Transmissive
3.50 inch	70.08 * 52.56 mm	Normally White TN, Transmissive
3.50 inch	70.08 * 52.56 mm	Normally Black IPS, Transmissive
4.00 inch	51.84 * 86.4 mm	Normally Black IPS, Transmissive
4.00 inch	71.86 * 70.18 mm	Normally Black IPS, Transmissive
4.30 inch	95.04 * 53.86 mm	Normally White TN, Transmissive
4.30 inch	95.04 * 53.86 mm	Normally Black IPS, Transmissive
5.00 inch	110.88 * 62.83 mm	Normally White TN, Transmissive
5.00 inch	108.00 * 64.8 0mm	Normally Black IPS, Transmissive
5.50 inch	68.04 * 120.96 mm	Normally Black IPS, Transmissive
6.00 inch	74.52 * 132.48 mm	Normally Black IPS, Transmissive
7.00 inch	154.08 * 85.92 mm	Normally White TN, Transmissive
7.00 inch	153.6 * 90 mm	Normally White TN, Transmissive
7.00 inch	154.21 mm * 85.92 mm	Normally Black IPS, Transmissive
8.00 inch	107.64 * 172.22 mm	Normally Black IPS, Transmissive
9.00 inch	196.61 * 114.15 mm	Normally White TN, Transmissive
10.1 inch	135.36 * 216.58 mm	Normally Black IPS, Transmissive
