7" TFT 1024*600 IPS Display Screen High Definition Screen Module
1. Specification of IPS TFT LCD Display
| MODEL NO. | CH700WS10B |
| Module type | 7"TFT |
| Display Mode | IPS / Transmissive / Normally Black |
| Number of Dots | 1024*3(RGB)*600 |
| Viewing Direction | 80/80/80/80 |
| Module size | 164.9(W)*100.0(H)*3.5(T)mm |
| TFT Active area | 154.2144(W)*85.92(H)mm |
| TFT Dot pitch | 0.1506(W)*0.1432(H)mm |
| Interface | 24bit RGB interface |
| Backlight Type | White LED |
| Luminace | 600cd/m2 |
2. Description of IPS TFT LCD Display
* 7.0-inch color screen,support 16.7M color display,display rich
colors
* 1024(RGB)×600 resolution, clear display
* Using 24-bit RGB Interface
* Provide a rich sample program
* Industrial grade process standard, long-term stable work
* Provide underlying driver technical support
* Long term stable production and guaranteed supply
3. Quick Detail of IPS TFT LCD Display
Size Inch : 7"
Model Name : CH700WS10B
Model Size (W*H*T)mm : 164.9*100*3.5
Display Area (W*H)mm : 154.21*85.92
Color : 16.7M
Display Mode : Normally Black IPS,Transmissive
Viewing Angle : All
Viewing Direction : 80/80/80/80
Backlight Type : White LED
Connection : Connector
Pin number : 40
Interface : 24 RGB Interface
Luminace : 600Nits
Backlight - White LED 27 serise Connection
Operation Temp : -20~70 ℃
Storage Temp : -30~80 ℃
4. Drawings of IPS TFT LCD Display
5. Application of IPS TFT LCD Display
6. Our Service
(1) We provide custom LCD modules service on LCD brightness, FPC
and PIN assignment.
Meanwhile, this 7 inch LCD screen is available with resistive touch
screen and capacitive
touch screen with customizing availability as well.
(2) If you need to custom touch screen, we can custom for you with
your company LOGO,
requested dimension shape, color and FPC interface.
-Up to 10.1 inch.
-Touch Cover glass thickness available.
0.55mm, 0.7mm, 1.1mm, 1.8mm, 3.0mm, 4.0mm, 5.0mm (Above 3.0mm needs
sophisticated touch controller).
-We provide also tape bonding and OCA / LOCA optical bonding for
the LCD screen and touch screen you choose with our suggestions.
7. Why Choose Us ?
- Years of TFT LCD display and touch screen design and manufacturing
experience, flexible customization of products to meet different
product needs
- One-stop solution for touch screen and TFT LCD module assembly
- Fast delivery: 1-4 weeks, standard models have regular stock
- High quality: ISO9001 certified factory
8. FAQ
A1. Who are we?
Q1: We are a Chinese supplier specializing in the production of
color LCD monitors. Our customers are all over the world. The
current sales of our products in various regions of the world are
as follows: South Asia (10.00%), Southern Europe (10.00%), Northern
Europe (10.00%), Central America (10.00%), Western Europe (10.00%),
East Asia (10.00%), The Middle East (10.00%), Southeast Asia
(10.00%), Eastern Europe (10.00%), North America (10.00%).
A2. How do we guarantee quality?
Q2: Always try to produce samples before mass production;
Always perform a final inspection before shipment;
A3. What can you buy from us?
Q3: TFT LCD display panel, capacitive touch screen, resistive touch
screen, LCD touch screen.
A4. Why buy from us instead of other suppliers?
Q4: Many years of experience in producing and exporting capacitive
touch screens/resistive touch screens (maximum 10.1 inches) and TFT
LCD display panels (maximum 10.1 inches). We provide one-stop
service for TFT LCD touch screen production.
