4.3 Inch TFT IPS Display All Viewing Direction With RGB Interface
1. Specification of TFT IPS Display
| MODEL NO. | CH430WQ12D |
| Module type | 4.3"TFT |
| Display Mode | IPS/Transmissive/Normally black |
| Number of Dots | 480*3(RGB)*272 |
| Viewing Direction | ALL |
| Module size | 105.5(W)*67.2(H)*3.0(T)mm |
| TFT Active area | 95.04(W)*53.856(H)mm |
2. Description of TFT IPS Display
- ChengHao Display model CH430WQ12D is a color active matrix thin
film transistor (TFT) liquid crystal display (LCD) that uses
amorphous silicon TFT as a switching device. This model is composed
of a TFT LCD panel, a driving IC, a back-light and FPC.
- This TFT LCD has a 4.3 (Horizontal screen) inch diagonally
measured active display area with 480 horizontal by 272 vertical
pixel.
- The driver used for this project is the ST7282 and can display
16M / 65K / 262K (Optional) colors by R.G.B. signal input. The
driver is mounted on the glass and the interconnection via FPC
including components to drive the display module. Support RGB
interface.
- In addition, FPC can also be customized according to customer
requirements, such as modifying back-light and CTP structure,
interface definition, etc.
- RoHS Compliance & Halogen Free.
3. Quick Detail of TFT IPS Display
* LCD name: 4.3 Inch TFT IPS Display 300cd/M2 All Viewing Direction
Lcd Module With Rgb Interface
* Part No.: CH430WQ12D
* Size.: 4.3 inch
* With touch panel or not: NO
* Display type: TFT
* Display colors: 16.7M/262K/165K
* Resolution (pixels): 480(RGB)*272
* Viewing direction: 80/80/80/80
* Controller IC: ST7282
* Display mode: IPS/Transmissive/Normally black
* Overall size: 105.5(W)*67.2(H)*3.0(T) mm
* Viewing area: 96.04(W)*54.86(H) mm
* Active Area: 95.04(W)*53.856(H) mm
* Luminance: 300 cd/m2
* Interface type: SPI/(SPI+RGB)/MCU /MIPI (optional)
* Pin NO: 40pins
* Connecting type: plugging type
* Backlight type and color: LED backlight/white
* LED Life span: 20000h
4. Drawings of TFT IPS Display
Notes:
(1) Display Type : 4.3" TFT
(2) Viewing Direction : All
(3) Lcd Drive IC : ST7282
(4) Operating Temp : -20~70 ℃
(5) Storage Temp : -30~80 ℃
(6) Unmarker Tolerance: ±0.20
(7) Protection : ROHS
5. Application of TFT IPS Display
4.3 inch TFT IPS Display,widely used in
medical,communication,instruments and other Application.
