3.5" Resistive LCD Display 320x480 Resolution IPS TFT LCD Module
3.5" Resistive Touch Screen Monitor 320x480 Resolution IPS TFT LCD
Module
1. Specification
| ITEM | STANDARD VALUES | UNITS |
| LCD type | 3.5’’TFT | -- |
| Dot arrangement | 320(RGB)×480 | dots |
| Color filter array | RGB vertical stripe | -- |
| Display mode | IPS/ Transmission/ NormallyBlack | -- |
| Viewing Direction | 80/80/80/80 | -- |
| Driver IC | ILI9488 | -- |
| Module size | 56.54(W)×84.96(H)×3.5(T) | mm |
| Active area | 48.96(W)×73.44(H) | mm |
| Dotpitch | 0.153(W)×0.153(H) | mm |
| Interface | 4-lines_8bit / 3-lines_9bit SPI
8-/ 9-/16-/18-bit8080system interface
16-/18-bitRGB interface | -- |
2. Description
Display model CH350HV40A-T is a color active matrix thin film
transistor (TFT) liquid crystal display (LCD) that uses amorphous
silicon TFT as a
switching device. This model is composed of a TFT LCD panel, a
driving circuit, Resistive Touch Panel
and a back light system. This TFT LCD has a 3.5 inch diagonally
measured active display area with 320*480 dot (320 horizontal by
480 vertical
pixel) resolution.
3. Drawings
4. Application
We are a professional manufacturer of tft display modules. Our tft
display modules include two types without touch screen and with
touch screen. Among them, the module with touch panel is divided
into two types: TFT capacitive touch module and TFT resistive touch
module. The main TFT display module size is between 1.44 and 12.3
inches, which is mainly used in industrial equipment, medical
equipment, automotive display equipment, office electronic
equipment, etc.
5. Our Service
1. We are a professional manufacturer of tft displays. The company
is equipped with a professional production R&D department and
can provide you with remote technical services at any time.
2. 24-hour online customer service can answer your questions at any
time.
3. In order to eliminate your worries about cooperating with us, we
provide up to twelve-month billing guarantee service for your
order!
4. Every product we send to you has undergone strict quality
inspection before leaving the factory to ensure that the products
you sign for meet your requirements.
7. FAQ
Q:How to control the quality of products?
A: The company has a professional quality team, and all products
are 100% inspected before shipment.
Q: How long is the warranty and service of the product?
A: Generally the warranty period is one year. It depends on
different products.
We guarantee our products to be free from manufacturer defects.
Liability under this warranty is limited to the replacing of any
product found to be defective under normal use.
Q: What certification could provide ?
A: Products by RoHS, CE, SGS certification.
Q: Can you provide product drawings and test reports?
A: According to customer needs, our company can provide product
related information and test reports.
Q:The product specification is in Chinese or English?
A:The version of product specification is English.
Q: What is the minimum order quantity?
A: All our products have MOQ requirement, please contact our
salesman for detailed information.
Q: Are you open to OEM processing?
A: Yes, we can OEM.
Q: What is the products application?
The products can be widely applied to the fields of HMI, handheld
terminals, household medical products, instruments and
apparatus, white goods, oiling machine, auto and AOI, etc.
