4.3 Inch TFT LCD Capacitive Touchscreen 480x800 Touchscreen Module
4.3 Inch Tft Lcd Display 480x800 Resolution touchscreen module with
Capacitive touch panel
1. Specification
| MODEL NO | CH430WV15A-CT |
| module type | 4.3 inch TFT + CTP |
| Resolution | 480*800 dots |
| Viewing Direction | All |
| control unit | NT35510 |
| Capacitive touch panel type | G+F+F |
| Surface Treatment | 6H |
| Capacitive touch panel | GT911 |
| Surface Treatment | 6H |
| Module size | 66.26(W)×113.9(H)×3.35(T) mm |
| TFT/CTPActive area | 56.16(W)×93.6(H) mm |
2. Description
Product Name:
4.3 Inch Tft Lcd Display 480x800 Resolution Touchscreen Module With
Capacitive Touch Panel
Display model CH430WV15A-CT is a color active matrix thin film
transistor (TFT) liquid crystal display (LCD)
that uses amorphous silicon TFT as a switching device. This model
is composed of a TFT LCD panel, a driving
circuit , A capacitive touch panel ,and a back light system. This
Capacitive touch LCD module has a 4.3 inch
diagonally measured active display area with 480x800 dot (480
horizontal by 800 vertical pixel) resolution.
3. Drawings
Notes:
(1) Display Type : 4.3inch TFT+CTP
(2) Viewing Direction : 80/80/80/80
(3) Lcd Drive IC : NT35510
(4) Polarizer Mode : Transmissive / Negative
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS
4. Application
Our products are widely used for banking machines, communication
tools, household appliances,
automobile instruments, mobile phone, video door phone, E-book,
stock mobile, MP5, tablet PC,
GPS navigator and so on.
5. Why Choose Us ?
The high quality products enable it to build a long-term
relationship with world-famous enterprises in the
industries.
(1) Competitive Price
Own-owned factories offer lower prices and better quality
assurance.
(2) Strong Technical Strength
We are a top supplier specializing in the production of color LCD
screens. We have a technical team with
rich experience in product research and development, and can
provide customers with professional tech
-nical support and customized consulting services at any time,
which is very important for cooperative
customers with special project needs.
(3) Long-term Partner
Products are sold to more than 40 countries, so from Chenghao
Optoelectronic you can get more stable
supplying promise;
(4) Professional Service
We have a professional after-sales team that can provide you with
after-sales consulting services 24 hours
a day.At the same time, if you encounter any problems in the
process of using our products, you can give
us feedback, and our technical engineers will provide you with
online remote consulting services at any time.
(5) Quality to be ensure
All panels are 100% brand new, without false panels; All packages
have labels and serial numbers for easy
viewing by customers;
6. FAQ
Q1: Are you manufacturer ?
A: Yes, we are manufacturer.
Q2: How long is your delivery time?
A: Normally 3-5 working days after payment; Special requirement
orders, delivery time is negotiable.
Q3: If the products can't work after receiving it,what should I do?
A: We will replace new items for you at once and then we make the
judgement for the issue.
Q4: Do you accept OEM design?
A: Yes,we do.We can design according to your requirement, MOQ
usually 100-1000.
Q5: Do you accept pay 30% in advance?
A: Yes,we do.We can start to prepare your goods when receive 30%
payment, and send them after get the rest 70% payment.
Q6: What payment terms you accept?
A: We accept Paypal, T/T, Western Union, Wechat, Alipay, in Cash
(RMB or USD).
