6.8inch IPS Capacitive Touchscreen High Resolution LCD Display
Module
6.8 Inch Ips Capacitive Touchscreen 480x1280 Hight Resolution LCD
Display Module
1. Specification
| MODEL NO. | CH068HWH12D |
| Module type | 6.86"TFT + TP |
| Display Mode | IPS / Transmissive / Normally Black |
| Number of Dots | 480*1280 |
| Viewing Direction | ALL |
| Brightness | 450 cd/m2 |
| TFT Active area | 6022mm×16059 mm |
| Interface | 18 bits RGB |
| Color | 262 K |
2. Quick Detail
Product Name: 6.8 Inch Ips Capacitive Touchscreen 480x1280 Hight Resolution Lcd
Display Module
Display mode: TFT LCD IPS full view angle
Backlight Type: Whilte LED
Dimension: Refer to Drawing
Color: 262K
Brightness: 450 cd/m2
Active Area: 60.22mm×160.59 mm
Touch panel type: CapacitanceTouch panel
Resolution: 480RGB×1280 dots
Other hardware: Two channel stereo with 2 Watt audio amplifier ,
RTC
Special features: Multi-media play,boot video support
Interfact: 18 bits RGB
3. Drawings
Notes:
(1) Display Type : 6.86" TFT+TP
(2) Viewing Direction : 80/80/80/80
(3) Polarizer Mode : IPS/ Transmissive/ NormallyBlack
(4) Protection : ROHS
4. Application
5. Why Choose Us ?
The high quality products enable it to build a long-term
relationship with world-famous enterprises in the industries
(1) Competitive Price
Own-owned factories offer lower prices and better quality
assurance.
(2) Strong Technical Strength
We are a top supplier specializing in the production of color LCD
screens. We have a technical team with rich experience in product
research and development, and can provide customers with
professional technical support and customized consulting services
at any time, which is very important for cooperative customers with
special project needs.
(3) Long-term Partner
Products are sold to more than 40 countries, so from Chenghao
Optoelectronic you can get more stable supplying promise;
(4) Professional Service
We have a professional after-sales team that can provide you with
after-sales consulting services 24 hours a day.At the same time, if
you encounter any problems in the process of using our products,
you can give us feedback, and our technical engineers will provide
you with online remote consulting services at any time.
(5) Quality to be ensure
All panels are 100% brand new, without false panels; All packages
have labels and serial numbers for easy viewing by customers;
7. FAQ
Q1: Are you manufacturer ?
A: Yes, we are manufacturer.
Q2: How long is your delivery time?
A: Normally 3-5 working days after payment; Special requirement
orders, delivery time is negotiable.
Q3: If the products can't work after receiving it,what should I do?
A: We will replace new items for you at once and then we make the
judgement for the issue.
Q4: Do you accept OEM design?
A: Yes,we do.We can design according to your requirement, MOQ
usually 100-1000.
Q5: Do you accept pay 30% in advance?
A: Yes,we do.We can start to prepare your goods when receive 30%
payment, and send them after get the rest 70% payment.
Q6: What payment terms you accept?
A: We accept Paypal, T/T, Western Union, Wechat, Alipay, in Cash
(RMB or USD).
