4.3 Inch Touch Screen Custom 480x272 Dots Serial Port Ips Lcd
Display With LT7680 TFT Driver IC
1. Specification
| Type: | TFT |
| Viewing Direction | 80/80/80/80 |
| Connection type: | COG+FPC |
| Operating temperature: | －20℃~70℃ |
| Storage temperature: | －30℃~80℃ |
| Driver IC: | LT7680 |
| Interface type: | SPI |
| Brightness: | 300 CD/㎡ |
2. Description
* 4.3-inch color screen display
* 480*272 resolution, clear display
* Using SPI Interface
* Provide a rich sample program
* Military-grade process standards, long-term stable work
* Provide underlying driver technical support
* Long term stable production and guaranteed supply
* Support customized service! Customizable content includes
FPC/backlight brightness/installation of touch panel, etc.
3. Drawings
Notes:
(1) Display Type : 4.3" Tft lcd
(2) Viewing Direction : 80/80/80/80
(3) Lcd Drive IC : LT7680
(4) Polarizer Mode : IPS / Transmissive / Normally Black
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS
4. Qucik Detail
* LCD name: 4.3 Inch Touch Screen Custom 480x272 Dots Serial Port
Ips Lcd Display With LT7680 TFT Driver IC
* Part No.: CH430WQ16A-CTC
* Size.: 4.3"
* Support touch panel Type: Capacitive Touch Panel
* Display type: 4.3"TFT
* Display colors: 16.7M / 262k / 65k ( Optional )
* Resolution (pixels): 480*272 cd/m2
* Viewing direction: 80 / 80 /80 /80
* TFT Controller IC: LT7680
* CTP Controller IC: GT911
* Display mode: Transmissive / Normally Black / IPS
* Overall size: 183.53 × 119.4 × 5.65 mm
* Active Area: 295.04 × 53.86 mm
* Luminance: 300 cd/m2
* Contrast: 800 : 1
* Interface type: SPI
* Pin NO.: 10 pins
* Pin pitch: 0.5 mm
* Backlight : 300 nits
* TP NOTE:
1.Glass Lens + ITO Glass + FPC + adhesive
Glass Lens:1.8 mm
Glass sensor: 0.55 mm
IC: GT911
2.Operation Voltage:2.8V-3.3 V
3.Transmittance:≥87％
4.The cover hardness:6H
* OPERATING TEMP: -20°C ~ +70
* STORAGE TEMP: -30°C ~ +80°C
* UNMARKER TOLERANCE: ±0.20
* IREMENTS ON ENVIRONMENTAL PROTECTION: RoHS
