IPS Lcd Touch Screen Monitor 2.4 Inch 240x320 All Viewing Direction
TFT Lcd Module
1. Specification of Thin Lcd Display
| MODEL NO. | CH240QV52A-CTB |
| Module type | 2.4"TFT + CTP |
| Display Mode | IPS / Transmissive / Normally Black |
| Number of Dots | 240*3(RGB)*320 |
| Viewing Direction | ALL |
| Module size | 52.72(W)*70.26(H)*4.0(T)mm |
| TFT Active area | 36.72(W)*48.96(H)mm |
| Interface | SPI,MCU,SPI+RGB |
| Luminace | 300cd/m2 |
2. Description of Color Lcd Display
ChengHao Display model CH240QV52A-CTB is a color active matrix thin
film transistor (TFT) liquid crystal display (LCD) that uses
amorphous silicon TFT as a switching device. This model is composed
of a TFT LCD panel, a driving IC, a back- light, a capacitive touch
panel and FPC.
This TFT LCD has a 2.4 (portrait) inch diagonally measured active
display area with 240*320 dots resolution, while using ST7789
mounted on glass as control IC. TFT Lcd Module uses SPI / MCU / SPI
+ RGB multiple interfaces, It can display 262k / 65K colors. In
addition, the module has a capacitive touch panel with I2C
interface, which supports multi-touch.
In addition, FPC can also be customized according to customer
requirements, such as modifying back-light and CTP structure,
interface definition, etc.
RoHS Compliance & Halogen Free.
3. Drawings of IPS Display Screen
Notes:
(1) Display Type : 2.4 inch Tft + CTP
(2) Viewing Direction : All
(3) Lcd Drive IC : ST7789
(4) Polarizer Mode : IPS / Transmission / Normally Black
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS
4. Application of IPS Capacitive Touchscreen
Telecommunication Devices : Telephone,interphone,watch,tablet
PC,radio,etc
Consumer Products : Camera,DVD player,toy, Cell Phone,game
player,etc
Technical Equipment : Elevator controller,Industrial machine,etc
Office Automation : Printer,scanner,attendance machine,fax
machine,etc
Home Appliances : Air-condition display,refrigerator,electric
cooker,video doorbell,etc
Automobile : GPS,video player,speedometer,audio broadcast,etc
IT Products : Camera,handheld digital video,projector,media
play,tablet PC,etc
Medical Equipment : Ultrasound machine,therapeutic equipment Blood
pressure meter,etc
