Rgb Lcd Display Module 5 Inch 800*480 24 Bit 40 Pin Tn Tft Lcd
1. Specification of tft display screen
| Module No. | CH500WV03A |
| Display Type | 5.0 inch TFT-LCD |
| Pixel Configuration | RGB Stripe |
| Display Resolution | 800*3(RGB)*480 dot |
| Contrast | 500:1 (Typ.) (TM) |
| Overall Size | 120.7(W)×75.8(H)×3.0(T) mm |
| Active Area (A.A) | 108(W)×64.8(H) mm |
| Luminace | 300 cd/m2 |
| Viewing Direction | 12 O’ clock |
| Interface | 24 bit RGB |
2. Description of tft color display
Chenghao CH500WV03A is a color active matrix TFT (thin film
transistor) LCD (liquid crystal display) that uses amorphous
silicon TFT as a switching device. It consists of a Tn Tft Lcd
Panel of 800*480 dots Resolution, a driver IC, a backlight and a 50
pin FPC.
The driver IC is mounted on the glass and interconnected with other
components through the FPC. By inputting RGB signals to it, the
display screen can display 16M colors. 12 white LEDs are used as
the light source of this module to provide a backlight of 300 nit
luminance for the Tft Screen Panel.
CH500WV03A adopts 24-bit Parallel RGB Interface and supports FPC
modification and customization. We can customize FPC according to
customer's requirements, including FPC shape structure, interface
definition, etc. In addition, this module can also be installed
with a touch panel. The types of installed touch panels include
capacitive touch panel and Resistive touch Panel.
RoHS Compliance & Halogen Free.
If CH500WV03A does not meet your project requirements, please
contact us, we have many display solutions similar to this module
for you to choose.
3. Drawings of tft colour monitor
Notes:
(1) Display Type : 5 inch Tft
(2) Viewing Direction : 12 O’clock
(3) Polarizer Mode : Tn / Transmission / Normally While
(4) Operating Temperature : -20~70 ℃
(5) Storage Temperature : -30~80 ℃
(6) Unmarker Tolerance: ±0.20
(7) Protection : ROHS
4. Application of tft lcd color monitor
