10.1 Inch Small Color Lcd Display 1024*600 50 pin Rgb tft lcd
module
1. Specification of Tiny Lcd Screen
| ITEM | STANDARD VALUES | UNITS |
| LCD type | 10.1’’TFT | -- |
| Dot arrangement | 1024(RGB)× 600 | dots |
| Module size | 235(W) ×143(H)×5.(T) | mm |
| Active area | 223.72(W) ×126.28 (H) | mm |
| Operating temperature | - 20 ~ + 70 | ℃ |
| Storage temperature | - 30 ~ + 80 | ℃ |
| Back Light | 36 White LED In Paralle | -- |
| Weight | TBD | g |
2. Description of Small Lcd Panel
ChengHao Display model CH101WS03B is a color active matrix thin
film transistor (TFT) liquid crystal display (LCD) that uses
amorphous silicon TFT as a switching device.
This TFT LCD has a 10.1 (Horizontal screen) inch diagonally
measured active display area with 1024*3(RGB)*600 dots resolution.
The driver used for this project can display 16M colors by R.G.B.
signal input. The driver is mounted on the glass and the
interconnection via FPC including components to drive the display
module.
In addition, FPC can also be customized according to customer
requirements, such as modifying back-light and FPC structure,
interface definition, etc.
RoHS Compliance & Halogen Free.
Note: All our tft lcd modules support touch panel installation.
3. Drawings of Small Lcd Display
Notes:
(1) Display Type : 10.1" Tft lcd
(2) Viewing Direction : 12:00
(4) Polarizer Mode : Tn / Transmissive / Normally While
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS
4. Qucik Detail of Small Lcd Screen
* LCD name: 10.1 Inch Small Color Lcd Display 1024*600 50 Pin Rgb
Tft Lcd Module
* Part No.: CH101WS03B
* Size.: 10.1 inch
* Support touch panel Type: No
* Display type: 10.1”TFT
* Display colors: 16M
* Resolution (pixels): 1024*3(RGB)*600
* Viewing direction: 12 O’clock
* Display mode: TN/Transmissive/Normally white
* Overall size: 235*143*5 mm
* Active Area: 222.72*125.28 mm
* Luminance: 300 cd/m2
* Contrast: 500:1
* Interface: RGB
* Pin NO.: 50
* Pin pitch: 0.35 mm
* Backlight : 36 pcs While LED
* Operating temperature: -20 ~ +70 ℃
* Storage temperature: -30 ~ +80 ℃
