480*800 Spi Lcd Module 4.3 Inch Ips Tft Display With Rgb Interface
1. Specification of ips tft lcd panel
| Module number | CH430WV08A |
| Resolution | 480x800 dots |
| Active Area | 56.16(W)*93.6(H)mm |
| View angle | R/L/U/D 80/80/80/80(Deg) |
| Pixel Arrangement | RGB-stripe |
| Surface Treatment | Plant |
| Electrical Interface | Parallel RGB |
| Brightness | 400(cd/m2) |
| Contrast ratio | 800 |
2. Description of 4.3 ips tft lcd panel
Chenghao Display model CH430WV08A is a component of a small color
display, which mainly includes a tft lcd panel, driver IC,
backlight and FPC.
The tft lcd panel has a rectangular display area with a diagonal
measurement of 4.3 inches, which can display 480*800 resolution
video animations. Due to the use of ips full viewing angle display
technology, the 4.3 ips screen display has an ultra-wide viewing
angle.
In addition, as a supplier with rich experience in tft lcd
production and sales, chenghao can provide OEM customization
services for all tft lcd between 1.1~10.1 inch. The customization
content of tft lcd module includes CTP/RTP installation or removal,
BL modification, FPC design, interface definition, etc.
3. Drawings of 4.3inch ips tft lcd panel
Notes:
(1) Display Type : 4.3” TFT
(2) Viewing Direction : 80/80/80/80
(4) Polarizer Mode : Transmission / Nagative
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS
4. Qucik Detail of 4.3" ips tft lcd panel
Model No:CH430WV08A
Size :4.3 inch
Active Area:56.16(W)*93.6(H) mm
Panel Type:IPS Panel
Backlight:LED
Backlight Life:20,000 hrs
Resolution:480x800
Acpect Ratio:0.6
Contrast:800
Brightness : 400 cd/m
Viewing Angle:80/80/80/80
Response Time:******
Display Color:16.7 M
Operating Temperature:-20~70℃
Storage Temperature:-30~80℃
Touch:CTP,RTP (Optional)
Dimension (W*H*D):61.56(W)*104.65(H)*2.2(T)mm
Weight: TBG
Control IC:NT35510
Certificates:CE/ROHS
5. Application of 480x800 ips tft lcd panel
6. Our Service
(1) Fully / Semi-automated production line ensure the best quality.
(2) Custom Design,can specially meet your needs.
(3) Fast Delivery ,about 20 days for lead time
(4) Samples available on request; Small MOQ orders can be
negotiated.
(5) Provide best pre-sale and after-sale service to you.
