480x272 Colour Lcd Module 4.3" Ips Tft Screen With 10 Pin FPC
1. Specification of tft lcd display module
| Resolution | 480 × 3(RGB) × 272 |
| View angle | R/L/U/D 80/80/80/80(Deg) |
| Pixel Arrangement | RGB-stripe |
| Surface Treatment | Plant |
| Electrical Interface | SPI |
| Brightness | 300(cd/m2) |
2. Description of 4.3 tft lcd display module
ChengHao Display model CH430WQ16A is a color active matrix thin
film transistor (TFT) liquid crystal display (LCD) that uses
amorphous silicon TFT as a switching device. This model is composed
of a IPS TFT LCD panel, a driving IC, a back light and FPC.
This TFT LCD has a 4.3 (Landscape screen) inch diagonally measured
active display area with 480*3(RGB)*272 resolution.
The driver can display 16M colors by 24 bit R.G.B. signal input.
The driver is mounted on the glass and the interconnection via FPC
including components to drive the display module. Support SPI
interface.
In addition, FPC can also be customized according to customer
requirements, such as modifying back-light , interface definition,
etc.
RoHS Compliance & Halogen Free.
3. Drawings of spi tft lcd display module
Notes:
(1) Display Type : 4.3 inch ips tft
(2) Viewing Direction : ALL
(3) Polarizer Mode : Transmission / Negative
(4) Operating Temp : -20~70 ℃
(5) Storage Temp : -30~80 ℃
(6) Unmarker Tolerance: ±0.20
(7) Protection : ROHS
4. Application of 4.3 tft lcd screen module
5. Quick detail of 4.3 inch tft screen module
Diagonal Display Size: 4.3 inch
Interface Type: SPI
Resolution: 480(RGB)x272 pixels
Touch Screen: No
Backlight Type: LED
Display Mode: IPS / Transmissive / Normall White
Dimensions: 105.5(W)*67.2(H)*3.0(T)mm
Display Matrix Technology: TFT
Operating Temperature: -20°C ~ +70°C
Brightness: 300 cd/m²
Number of Colours:16M
Standards Met: CE, RoHS Compliant
Response Time: 10ms
Contrast Ratio: 800
Display Type: LCD TFT
FPC Number: 10
Life Time: 20000 Hr
6. FAQ
Q:Payment methods?
T/T, Paypal and Western union etc.
For samples: payment in advance.
For mass production: 50% deposit and 50% balance before shipment.
Q: What is the lead time of the products?
A:Samples in stock will be sent within 3 days after payment.
Two to Four weeks for mass production
Q:How long is the warranty period?
A:Generally the warranty period is one year. It depends on
different products.
Q:What is the Product MOQ?
A:Different product has the different MOQ, please contact us sales
for detailed information.
Q: What's your after-sale service?
A: If any problems, you will get our reply within 24 hours.
Solution will be offered instantly by our professional technical
team.
Q:Can you provide OEM service?
A:yes, we can provide both OEM and ODM service,can customize
products according to the drawings you supply
Q: How can I trust your product quality?
A:The company has advanced the incoming inspection, on-line test
and reliability test equipment and system, the company products
through the ROHS,CE testing
