480*272 dot matrix lcd display module 4.3inch SPI Screen with IPS
All Viewing Angle
1. Specification of 4.3 SPI Display
| ITEM | STANDARD VALUES | UNITS |
| LCD type | 4.3’’TFT | -- |
| Dot arrangement | 480(RGB)× 272 | dots |
| Module size | 105.5(W)*67.2(H)*3.0(T) | mm |
| Active area | 95.04(W)*53.856(H) | mm |
| Operating temperature | - 20 ~ + 70 | ℃ |
| Storage temperature | - 30 ~ + 80 | ℃ |
| Weight | TBD | g |
2. Description of 480x272 SPI Display
* CH430WQ16A is a Transmissive type color active matrix liquid
crystal display (LCD).
* It is composed of a IPS TFT LCD panel, driver IC, FPC, backlight.
* It is 480(RGB)x272 resolution TFT LCD module.
* Backlight with different brightness options from 200 - 1500cd/m2
are available.
* FPC can be customized, including shape structure, interface
definition, etc.
* The installation of a touch panel is supported.
* Specific touch panel can be designed & customized.
* RoHS & REACH compliant.
* If you can't find a suitable one, contact us to get a
recommendation.
3. Drawings of 4.3 SPI LCD module
Notes:
(1) Display Type : 4.3 inch IPS TFT
(2) Viewing Direction : ALL
(3) Polarizer Mode : Transmissive / Negative
(4) Operating Temp : -20~70 ℃
(5) Storage Temp : -30~80 ℃
(6) Unmarker Tolerance: ±0.20
(7) Protection : ROHS
4. Quick Detail of 480x272 spi LCD module
LCD type : 4.3" TFT
Dot arrangement : 480(RGB)*272 dots
Color filter array : RGB vertical stripe
Display mode : IPS/ Transmission/ Normally Black
Viewing Direction : 80/80/80/80
Module size : 105.5(W)*67.2(H)*3.0(T) mm
Active area:95.04(W)*53.856(H)mm
Interface TFT : SPI
Operating temperature: -20 ~ +70 ℃
Storage temperature: -30 ~ +80 ℃
Back Light: White LED
FPC Number:10
Weight: TBD g
5. Application of 4.3 ips tft display module
6. FAQ
Q:Payment methods?
T/T, Paypal and Western union etc.
For samples: payment in advance.
For mass production: 50% deposit and 50% balance before shipment.
Q: What is the lead time of the products?
A:Samples in stock will be sent within 3 days after payment.
Two to Four weeks for mass production
Q:How long is the warranty period?
A:Generally the warranty period is one year. It depends on
different products.
Q:What is the Product MOQ?
A:Different product has the different MOQ, please contact us sales
for detailed information.
Q: What's your after-sale service?
A: If any problems, you will get our reply within 24 hours.
Solution will be offered instantly by our professional technical
team.
Q:Can you provide OEM service?
A:yes, we can provide both OEM and ODM service,can customize
products according to the drawings you supply
Q: How can I trust your product quality?
A:The company has advanced the incoming inspection, on-line test
and reliability test equipment and system, the company products
through the ROHS,CE testing
