800x480 Resolution Small LCD Touch Screen 7.0 Inch 24 Bit Parallel
RGB Interface
1. Specification of 800x480 lcd touch screen
| Type: | TFT |
| Viewing Direction: | 12 o' Clock |
| Connection type: | COG+FPC |
| Operating temperature: | －30℃~80℃ |
| Storage temperature: | －30℃~80℃ |
| CTP Driver IC: | GT911 |
| Interface type: | RGB |
| Brightness: | 280 CD/㎡ |
2. Description of 800x480 touch lcd
ChengHao Display model CH700WV03A-CTA is a color active matrix thin
film transistor (TFT) liquid crystal display (LCD) that uses
amorphous silicon TFT as a switching device. It is mainly composed
of touch panel, tft lcd panel, backlight, driver IC and FPC.
(1) The touch panel is capacitive and uses the I2C interface to
interconnect with other components. The glass cover attached to CTP
can be customized according to customer requirements.
(2) The Back light uses 21 White LED as the light source, which can
make the 7 inch lcd touchscreen produce a luminance of 280 cd/m2.
(3) The TFT FPC uses 24-bit Parallel RGB Interface, and the FPC
Number is 40 pins, which can be customized according to customer
requirements. The customized content includes shape structure,
interface definition, etc.
(4) The tft lcd panel has a 7.0inch display area, which can display
800*3(RHB)*480 images.
3. Drawings of 800x480 small tft lcd
Notes:
(1) Display Type : 7.0” TFT
(2) Viewing Direction : 12:00
(4) Polarizer Mode : Transmission / Positive
(5) Operating Temp : -20~70 ℃
(6) Storage Temp : -30~80 ℃
(7) Unmarker Tolerance: ±0.20
(8) Protection : ROHS
4. Qucik Detail of 800x480 tft lcd screen
LCD type : 7.0"TFT+CTP
Dot arrangement : 800×3(RGB)×480 dots
Color Pixel Arrangement : RGB vertical stripe
Display Mode : TN / Transmissive / Normally white
Viewing Direction : 12 o’clock
Gray Scale Inversion Direction : 6 o’clock
CTP type : LENS Glass+ITO Glass+FPC+Adhesive
Surface Treatment : 6H
CTP Driver IC : GT911
Module size : 180(W)×119(H)×5.27(T) mm
TFT/CTP Active area : 154.08(W)×85.92(H) mm
TFT Dot pitch : 0.1926 (W)×0.1790 (H) mm
Interface : 24-bit Parallel RGB Interface
Operating temperature : -20 ~ +70 ℃
Storage temperature : -30 ~ +80 ℃
Back Light : 21 White LED
Weight : TBD g
5. Application of 800x480 tft screen
Telecommunication Devices Telephone, Interphone, watch, radio, etc.
Home Appliances Washing Machine, Refrigerator, Home Integrator etc
Industrial Control Homotaxial Numerically-controlled machine tool
Instrument and Apparatus Tester, Medical instruments
Vehical-mounted Digital MP3, MP4 and vehical-mounted air
conditioner
Mining Mine's lamp charger, gas tester
Marine Salinity tester
According to customers' various requests,TFT lcd, lcd panel, lcd
monitor, lcd screen, FSTN and STN lcd display, industrial lcd, we
can match all accessories which inclusive of driver board,LED
backlight & LVDS cables.
ODM/OEM accetable
Various LCD Display Mode with different backlight color and
temperature range available
