WQVGA Hight Brightness IPS LCD Display 4.3 Inch 480*272 10pin SPI
TFT Display
1. Specification
| Display Type | 4.3’’ TFT |
| Display model | IPS / Transmissive / Normally Black |
| Display Resolution | 480(RGB)×272 |
| Contrast | 800:1 |
| Overall Size | 105.5(W)×67.2(H)×3.0(T) mm |
| Active Area (A.A) | 95.04(W)×53.856(H) mm |
| Luminace | 1000 cd/m² |
2. Description
Chenghao Optoelectronic CH430WQ18A is a sunlight readable color tft
display, using SPI interface, when Vf=24.8v, If=40mA, the screen
brightness is 1000 cd/m2, it can be installed in various outdoor
equipment. There is a 4.3 inch dot matrix area of this hight
brightness tft display, which can display 480x272 pixel color
screen and 16M colors. This tft display adopts IPS display mode,
supports 80/80/80/80 full viewing angle, and can operate normally
for more than 20000 H in the temperature environment of -20~+70°C.
In addition, this 4.3 inch tft display can be modified and
customized according to customer requirements. The customizable
content includes screen brightness, interface definition, touch
function, FPC shape and screen anti-glare, etc.
CH430WQ08A is a color tft display installed on access control
equipment. It has passed FCC, CE, RoHS certification, and provides
more than one year of warranty service. If you want to get more
information about this color tft display, welcome to contact us by
email or online customer service.Chenghao Optoelectronic CH430WQ18A
is a sunlight readable color tft display, using SPI interface, when
Vf=24.8v, If=40mA, the screen brightness is 1000 cd/m2, it can be
installed in various outdoor equipment. There is a 4.3 inch dot
matrix area of this hight brightness tft display, which can display
480x272 pixel color screen and 16M colors. This tft display adopts
IPS display mode, supports 80/80/80/80 full viewing angle, and can
operate normally for more than 20000 H in the temperature
environment of -20~+70°C. In addition, this 4.3 inch tft display
can be modified and customized according to customer requirements.
The customizable content includes screen brightness, interface
definition, touch function, FPC shape and screen anti-glare, etc.
CH430WQ08A is a color tft display installed on access control
equipment. It has passed FCC, CE, RoHS certification, and provides
more than one year of warranty service. If you want to get more
information about this color tft display, welcome to contact us by
email or online customer service.
3. Drawings
Notes:
(1) Display Type : 4.3’’ TFT
(2) Viewing Direction : 80/80/80/80
(3) Operating Temp : -20~70 ℃
(4) Storage Temp : -30~80 ℃
(5) Unmarker Tolerance: ±0.20
(6) Protection : ROHS
4. Qucik Detail
Product Name:WQVGA Hight Brightness IPS LCD Display 4.3 Inch
480*272 10pin SPI TFT Display
Model No:CH430WQ18A
LCD type:4.3’’ TFT
Dot arrangement:480(RGB)×272 dots
Color filter array: RGB vertical stripe
Display mode: IPS / Transmissive / Normally Black
Viewing Direction:80/80/80/80
TFT Driver IC:***
Color:16M
Contrast:800
Module size:105.5(W)×67.2(H)×3.0(T) mm
TFT Active area:95.04(W)×53.856(H) mm
Dot pitch:0.198 (W)×0.198 (H) mm
TFT Interface:SPI
FPC Pin Number:10
Operating temperature: -20 ~ +60 ℃
Storage temperature: -30 ~ +70 ℃
Back Light:16 pcs White LED
5. Application
6. FAQ
A Q: When can i get the quotation?
A: We usually quote within 12 hours after we got your inquiry.
If it is very urgent, please call us or contact us via email, Skype
or WhatsApp.
Q: What is your warranty?
A: We provide one year warranty.
Q: May i buy samples from you?
A: Yes! You are welcome to place sample order to test our Hight
quality and service.
Q: How to place bulk order?
A: 1) Tell us model number, quantity, color and other special
requirements.
2) Proforma Invoice will be made and sent to you for approval
3) Production will be arranged once get your payment or deposit.
4) Goods will be delivered as stated on the Proforma Invoice.
Q: How will you deliver my goods to me?
A: We provide as many shipping options as possible, such as DHL,
UPS, FEDEX, TNT AND EMS to enable our customers get their goods
rapidly at door. We also ship by economick method such as air cargo
and sea cargo, direct line, air mail according to customers'
request.
