Wqvga Industrial LCD Display Module 1000 nit 480*272 10pin Color Tft Display

1. Specification

2. Description

Chenghao Display CH430WQ17A is a Hight Brightness tft lcd module with SPI interface, the brightness is 1000 cd/m2, and it supports sunlight readability. The 4.3inch lcd display has a storage temperature of -30~+80°C and can operate normally for more than 20K H in an environment of -20~+70°C. There is a 480*272 pixel color display area of this 4.3" display, which can display 16M color video images.
CH430WQ17A is a high-brightness color LCD module developed and designed for installation on children's drawing boards. It has completed RoHS, CE, and FCC certifications, and can provide buyers with more than one year of warranty service. At the same time, this 4.3 tft lcd is also a customized LCD module. Some components or functions can be modified according to the customer's project requirements. The customized content includes flexible circuit boards, interface types, touch functions, and backlight brightness.
Of course, as a comprehensive enterprise integrating production and trade, Chenghao Display can customize professional display solutions for you according to your personal wishes. You can get interested information by consulting online customer service or sending us emails. We Look forward to working with you!

3. Drawings

Notes:
(1) Display Type : 4.3 inch TFT
(2) Viewing Direction : 12 o’clock

(3) Lcd Drive IC : ****
(4) Operating Temp : -20~70 ℃
(5) Storage Temp : -30~80 ℃
(6) Unmarker Tolerance: ±0.20
(7) Protection : ROHS

4. Quick Detail

Product Name: Wqvga Industrial LCD Display Module 480*272 10pin Color Tft Display
Model No:CH430WQ17A
With or Without TP:no
Support TP Type:CTP/RTP
LCD type:4.3"TFT
Dot arrangement:480*272-RGB
Color filter array: RGB vertical stripe
Display mode: TN / Transmissive / Normally White
Viewing Direction:12:00
TFT Driver IC:***
Color:16M
Contrast:500:1
Module size:105.5×67.2×3.0 mm
TFT Active area:95.04×53.856 mm
Dot pitch:0.198×0.198 mm
TFT Interface:SPI
FPC Pin Number:10
Operating temperature: -20 ~ +60 ℃
Storage temperature: -30 ~ +70 ℃
Back Light: White LED
Weight: *** g

5. Our Service

(1) Fully / Semi-automated production line ensure the best quality.
(2) Custom Design,can specially meet your needs.
(3) Fast Delivery ,about 20 days for lead time
(4) Samples available on request; Small MOQ orders can be negotiated.
(5) Provide best pre-sale and after-sale service to you.
