Product Description:
Chenghao Display model CH104SV01A-CT-PB is an LCD module that
utilizes amorphous silicon TFT as a switching device. This module
includes a touch panel, an LCD display screen, and a PCB board. The
LCD display screen consists of a touch panel, a TFT LCD panel, a
driving IC, a back-light, and FPC.
The display screen is capable of outputting image content with
16.7M color and 800*600 pixels after inputting R.G.B. signal. It
has a 10.4 inch active display area and adopts
TN/Tranmissive/Normally White display mode. The best viewing angle
is at 12 o'clock, and it can operate at temperatures ranging from
-20 ~ +70℃. This display screen is compatible with SPI, RGB, MCU,
and other interfaces.
The touch panel on this module is a capacitive touch glass cover,
and it is equipped with a control chip model GT9271. The glass
cover can communicate with external devices through the I2C
interface, and it also supports multi-touch. The thickness of the
glass cover is 1.1 mm, and it is customizable to meet any
customer's requirements.
Finally, it is essential to note that this module is RoHS compliant
& Halogen-free, ensuring that it is environmentally friendly and
safe for public use.
| Module No | CH104SV01A-CT-PB |
| Resolution | 800*600 dots |
| Viewing Direction | 12:00 |
| Interface | SPI+RGB/MCU |
| Manufacturer | Chenghao Optoelectronic |
Features:
Chenghao Display's CH104SV01A-CT-PB is an outstanding custom LCD
display with an excellent cost performance ratio. This display
module is designed to deliver exceptional image quality with
premium features.
The display boasts a range of features, including:
- 12 O'clock Viewing Direction: To meet the requirements while adhering to cost constraints, the
display module utilizes TN/Transmissive/Normally white display
mode, ensuring that the optimal viewing angle of the display is
12:00.
- Support Wide Temperature: With a broad temperature range design, this full-color LCD screen
can operate effortlessly in a range of environments from -20 ~
+70℃. This feature is essential for machines and equipment that
need to function smoothly in extreme environments.
- Support Human-Computer Interaction: The display module comes with a sensitive capacitive touch glass
panel installed on the surface, which allows for the collection of
customer touch information and works with other elements to achieve
screen control feedback.
Technical Parameters:
Module Name:10.4 inch Lcd Touch Screen Module
Module No:CH104SV01A-CT-PB
Module Type: 10.4" TFT+CTP+PCB
Resolution: 800*600 dots
Display Mode: TN/Transmissive/Normally White
Viewing Direction: 12:00
Brightness: 800 cd/m2
Contrast: 500
Color: 16.7M
Touch Type: Capacitive
Touch Interface: I2C
Touch Glass Cover's lens: 1.1 mm
Operating Temperature: -20 ~ +70 ℃
Storage Temperature: -30 ~ +80 ℃
Applications:
Chenghao Display has designed and customized CH104SV01A-CT-PB, a
10.4 inch LCD display module, specifically for industrial
equipment.
This display module has several functional parameters that can be
modified and adjusted as per customer requirements. This feature
makes it highly versatile and suitable for a wide range of uses,
including in home appliances, automobile transportation, Internet
of Things equipment, medical equipment, and other similar
industries.
Overall, Chenghao Display has created a display module that allows
for flexibility and adaptability to meet the needs of various
industries.
FAQ:
Q1: What is the brand name of this product?
A1: The brand name of this product is Chenghao Optoelectronic.
Q2: What is the model number of this product?
A2: The model number of this product is CH104SV01A-CT-PB.
Q3: Where is this product manufactured?
A3: This product is manufactured in China Shenzhen.
Q4: Does this product have any certifications?
A4: Yes, this product is certified with RoHS, CE, and FCC
certifications.
Q5: What is the minimum order quantity for this product?
A5: The minimum order quantity for this product is 100 pcs.
Q6: How is this product packaged?
A6: All the products are packed in the right way to keep it safe.
For small sizes of products, we use tray + carton, for bigger sizes
we use foam slot + carton. We also design packages according to
customers' requirements.
Q7: What is the delivery time for this product?
A7: The delivery time for this product is 3~7 days.
Q8: What are the payment terms for this product?
A8: The payment terms for this product are TT.
Q9: What is the supply ability for this product?
A9: The supply ability for this product is 300K pcs/month.
